EDI ultra-pure water power supply
| Specifications | 100 | 150 | 200 | 300 | 400 | 500 | 600 | 800 | 1000 | 1500 |
| Rated current | 100A | 150A | 200A | 300A | 400A | 500A | 600A | 800A | 1000A | 1500A |
| Dimensions (MM) (length, width, height) | 335*165*214 | 420*245*238 | 435*265*255 | 435*265*255 | 570*395*245 | 675*479*292 | 770*479*291 | Custom sizing | ||
| Power parameters | Main circuit: AC50-380V; Control board power supply: AC160-240V; Frequency: 45HZ-65HZ | |||||||||
| Cooling method | Air cooling | |||||||||
| Protection function | Protection functions such as phase loss, overcurrent, overheating, overload, load disconnection, frequency, etc | |||||||||
| Port | 0-5V/0-10V/0-20mA/4-20mA analog input, 3-channel switch input, 1-channel switch output; MODBUS-RTU | |||||||||
| Extension module | / | |||||||||
| Control mode | Constant voltage, constant current, open-loop control | |||||||||
| Load type | Resistive, inductive, customizable according to specific loads | |||||||||
| Accuracy | ≤1% | |||||||||
| Static Stability | ≤0.2% | |||||||||
| Usage environment | 0.025% | |||||||||
Temperature control system solution
We integrate the company’s superior product resources and, based on different temperature control systems, formulate reasonable solutions and deliver the entire temperature control system’s software and hardware to provide users with a one-stop service, eliminating customers’ worries. The solutions we have provided so far include push-plate kiln solutions, bell jar kiln solutions, shoe-making machinery solutions, painting machinery solutions, roller conveyor kiln solutions, and high-temperature kiln solutions. We are constantly expanding these solutions.
phase thyristor power regulators support resistive and inductive loads. Some applications thyristor power regulator widely be used:
1.Holding Furnaces
2.Silicon Carbide/MoSi2 heating elements furnaces
3.Aluminium Melting Furnaces
4.Air Handling Units
5.Dehumidifiers
6.Boilers
7.Multi-zone heating for manifold moulds
8.Hot Air Generators and Hot Air Dryers
9.Paper and Printing Drying Ovens
10.Microwave dryers
11.Multi-zone Drying and Curing Ovens
12.Heat Transfer Printing Machines
13.Preheating tunnel ovens made using IR heaters
14.Plastic Pipes and Sheets extrusion
15.Metal sheets welding systems
Customer service
1. ODM/OEM service is offered.
2. Quick order confirmation.
3. Fast delivery time.
4. Convenient payment term.
At present, the company is vigorously expanding overseas markets and global layout. We are committed to becoming one of the top ten export enterprises in China’s electrical automatic product, serving the world with high-quality products and achieving a win-win situation with more customers.
